XCMG XCT 100

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 17756597429 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

XCMG XCT100 crane parameter configuration Lifting capacity Maximum rated lifting capacity (t) 100 Minimum working range (m) 3 The maximum rated lifting torque (KN.m) is 4380 Maximum lifting height - basic arm (m) 13.5 Maximum lifting height - full extension arm (m) 61.2 Maximum lifting height - basic arm jib (m) 78 Maximum lifting capacity (tons) 45-90 tons Maximum lifting capacity (tons) 45-90 tons Lifting arm size Lifting arm length - basic arm (m) 13.1 Job speed parameters Maximum lifting speed of main winch (m/min) 130 (no load) Maximum lifting speed of the sub-hoist (m/min) 130 (no load) The total extension time of the lifting boom (s) is 420 The luffing time of the crane boom (s) is 60 Rotation speed (rpm) 2 motor Chassis engine model ISM11E4 440/WP12.430 E40 Rated power (kw/rpm) 318/1900 316/1900 Get on the engine TAD722VE/BF6M1013EC Rated power (kw/rpm) 174/2300 Driving parameters The maximum travel speed (km/h) is 80 Minimum turning radius (m) 11.5 Maximum climb (%) 45 Approach/Departure Angle (°) 18/13 Minimum ground clearance (mm) 312 Specifications of the whole machine The total length of the whole machine (mm) is 15295 The overall width of the whole machine (mm) is 3000 The overall height of the whole machine (mm) is 3820 Total counterweight (t) 55 Wheelbase (mm) 1920 3500 1420 1505 Outrigger span Longitudinal × transverse (m) 7.7×7.9
